Mode | GD-1325-4 |
2D Working size | 1300*2500mm |
Z axis size | <500mm |
3D working size | Diameters 0-400mm Length:0-2000mm |
Table Structure | Steel Structure |
X Y Structure | Rack and Pinion TAIWAN HIWIN/PMI Square Guide Rails 20/25mm |
Z Structure | Germany TBI Ball Screw |
Spindle | 3.2KW water cooling.24000rpm/min |
Driver motor | China Stepper motor and leadshine driver |
Inverter | Fuling or Sunfar |
Control system | Nc studio/DSP |
Working Voltage | 380V/3PH/50HZ |
Command Code | G code |
Collet | ISO30 |
Software Compatibly | Artcam/Artengraver/Type3/V9/JD paint |
Running Temperature | 0-45 centigrade |
Relative Humidity | 30%-75% |
Color | Red and black / blue and white(option) |
sculptures and complex artworks, can easily engrave 360 degree Human body, Buddhist statues,etc.
FAQ
Q : How to install and maintain the machine ?
A Before you use it , we will send the operation tutoral and installation operation video with English version to youyou still can not operate , we will provide video guidance online
Q : What are the machine working environment requirements ?
A The machine should be fixed on a stable table and the environment should be kept clean and tidy to avoid contactwith dust , static electricity , humidity , and chips to cause parts failure .
Q : What about after-sales service ? How long is the warranty period ?
A We offer 24 hours online video call to solve your problems . We have a standby team ready to assist you at any giventime Machine maintenance requirement will be provided to youpurchase On all machinery we offer 1 yearwarranty and 6 months warranty for core components
Q : How many days does the goods ready to ship ?
A The specific delivery date needs to be communicated with the sale . f we have stock , t can be shipped within fivedays . If it is not in stock , it will take 15 to 20 days to prepare goods . By the way , Most of the machines are in stock
Q : What is the mode of transportation of the products ?
A The specific transportation method can be selected according to the needs , like by sea by air or by train . Our trade
