Production Introduction
Production Detail
|
|
| The operating system Operating system independent research and development, joint adapter machine, simple operation TOUCHWIN touch screen,Rest assured quality, stable work! | Electrical chassis Internal electrical order, with frequency conversion control, flexible frequency conversion adjustment, to adapt to a variety of sheet metal processing, improve the service life. |
|
|
| Material cylinder pressure Movable type high pressure cylinder, can be accurately fixed pressure plate,Sheet to prevent sliding, big rubber gasket sheet does not hurt. | Aggravating the fuselage Airframe adopt high strength PVC mesa, avoid mesa wear of the error,Machine adopts thick walled square steel, effectively avoid machine work time and inconvenience. |
Production Specification
Description | Parameters |
Dimension (L*W*H) | 3350*1770*1400mm |
Working speed | 10500mm/min |
Spindle travel speed | 24000RPM/MIN |
Table Surface | Vacuum Table |
Laser Head | Banner |
Frame | Heavy welded steel tube |
Structure | Ball screw, square rail |
Control System | Motion control system |
Servo System | Double servo system |
Traveling Positioning Accuracy | ±0.02mm/300mm |
Spindle Power | 2.2KW |
Working Voltage | 380V, 50/60HZ, 3ph |
N.W. | 1200KG |
Main Function | Drilling hole/Wooden pin hole/slotting |
Optional | 3.5KW spindle/Dust Exhaust Apparatus |
Production Sample
Company
Package and shipping
FAQ
1: I knew nothing about this machine, what kind of machine i should choose?
Very easy to choose. Just tell us what you want to do by using cnc router, then let us give you perfect solutions and suggestions.
2: When I got this machine, but I did not know how to use it. What should I do?
We will send video and English manual with the machine. If you still have some doubts, we can talk by telephone or skype.
3: If some problems happened to this machine during warranty period, what should I do?
We will supply free parts in machine warranty period if machine have some problem. While we also supply free after-service forever, so any doubts, just us know, we will give you solutions in 30 minuets.
4: What is the MOQ?
MOQ for our products is 1 set machine, we could send it to your country if you tell detail information about your country port.
