*Three axis with dust cover cloth structure,Ball screw&guide rails with auto oiling system,asuring ball
screw &guide rails long time working with no rust.
*High torque spindle,high rotating speed, small rotating shaking.lower noise.
*With X/Y/Z axis with all square linear guide ,bigger bearing redundance,longer life. Having longer life,
higher pricision comparing to the round guide rail.
*Easy operation,Humanization design, design.Machine processing more handy .
Parameter configuration table
Mode | GD-3030 | GD-6090 | ||
Working size | 300*300mm | 600x900mm | ||
Table Structure | Steel Structure | |||
X Y Structure | Rack and Pinion TAIWAN HIWIN/PMI Square Guide Rails 20/25mm | |||
Z Structure | Germany TBI Ball Screw | |||
Spindle | 3.2KW water cooling.24000rpm/min | |||
Driver motor | China Stepper motor and leadshine driver | |||
Inverter | Fuling or Sunfar | |||
Control system | Nc studio/DSP | |||
Working Voltage | 380V/3PH/50HZ | |||
Command Code | G code | |||
Software Compatibly | Artcam/Artengraver/Type3/V9/JD paint | |||
Relative Humidity | 30%-75% | |||
High power spindle
Aluminum alloy table
Helical rack
Helical rack
Rotary option
DSP controller
Professional suitable for copper.aluminum surface fast caving.
Professional suitable for varities of jade pendant ,omament etc fast carving.
Aiming for top grade crafts plane carving or 3d carving,such as pipe.olive nut wooden crafts etc.
Jinan Guandiao CNC Equipment Co., Ltd is an innovative enterprise engaged in research and development,
production, sales and good after- sales service.
Jinan Grandio CNC has16 years of production experience, 11 years of export experience, can provide hands-on
technical support, has an independent research and development team, can provide continuous product and
software upgrade and update services.Qualified after-sales technical teams in many countries, which can help
customers solve after-sales problems locally.
Even can help customers who with zero import experience to provide customs clearance to door service.Accept
customized and OEM production, with 4 main production workshops, cnc router engraving machines, fiber laser
cutting machines, other woodworking machinery, like sanding machine and pvc banding machine...Our new
workshop is for 3d scanners,like laser scanner, 3d Shining scanner, we provide the highest quality products, low
prices and the best service, one-stop shopping, for all customers Free agent purchasing service always looking for
powerful agent, work together, win-win.
The company has independent import and export right, products are exported to southeast Asia, the Middle East,
Africa, Europe and the United States and other places, and with its excellent quality, excellent performance and
perfect after -sales serves won the customer the consistent approval.
Our Services & Strength
2.Lifetime maintenance free of charge.
3.Free training course at our plant.
4.We will provide the consumable parts at an cost price when you need replacement.
5.24 hours on line service each day, free technical support.
6.Machine has been adjusted before delivery.
