Precision sliding table saw
The moving table is the key part of the sliding table saw and the main part different from the ordinary circular saw.
The moving table is composed of bracket, lower guide rail, roller, sliding table and other parts. Its remarkable characteristics are:
(1) light and labor-saving operation, large pushing stroke and large cutting width;
(2) It is equipped with a stable and light trailer, which runs smoothly;
(3) The setting of the mobile workbench and the main saw blade can be adjusted 45 degrees, which expands the application range of the saw. Some saw machines are also equipped with milling devices, which can process grooves and grooves with a width of 30-50mm.
Specification
Model | MJ45A | |||
Host shaft speed | 4000 /5000r/min | |||
Saw shaft speed slot | 9000r/min | |||
Max Thickness | 80mm | |||
Main blade shaft diameter | 300*30mm | |||
Sliding table stroke | 2800mm | |||
Tilt angle of the blade | 45°-90° | |||
Main saw motor | 5.5kw | |||
Groove saw motor | 1.1kw | |||
Master motor | 0.55kw(Adjustable speed) | |||
Slot Blade size | 120×20mm | |||
Weight | 1060kg | |||
Dimensions | 2960X3500×1000mm | |||
Air pressure | 6kg/cm2 | |||
Details
Electric lift Export lifting mode for electric lifting angle display for digital reading, plus accuracy and convenience. |
Step by step tighten the push table The adoption of the sharing platform makes it more stable and unstable deformation. The accuracy is more accurate by using Taiwan imported round bar double guide rail. The platform is step by step, cutting more precise. |
All copper motor The motor uses 5.5kw-1.1kw, aluminum shell all copper national standard motor to provide strong power for the machine. |
Convenient oil filling cup The lubrication mode of the export type push table saw is oil cup filling, and the ordinary type needs manual oil injection. |
Application
Applicable products:
MDF,particleboard,wood-based panels,ABS panels,PVC panels,plexiglass,solid wood and other wood structure and hardness similar to the plate.
Working principle:
hand move the mobile workbench before and after the move to achieve the sawing process,scribe saw sawing in advance,the main saw blade can be used to carry out variable speed sawing.
Achieved effect:
manual and easy to feed when the labor-saving,high precision,access to good quality sawing.
Structure advantages:
mobile workbench guide rail with high strength extruded aluminum alloy,high strength,non-deformation,chrome rod structure,high positioning accuracy,table surface oxidation treatment,beautiful wear-resistant.
Packing&Shipping
Company profile
1.15 years woodworking machinery experience
2. 8 years exportation experience
3. Engineer team with +20 years experience
4. We joined Alibaba Trade Assurance to make sure the buyer’s benefit.
5.Guarantee and After-sale service:
a. 12 months warranty for the whole machine
b. Technical support by phone, email or WhatsApp/Skype around the clock.
c. Friendly English version manual and operation video CD disk
d. Engineer available to service machinery overseas.
