CNC Wood Machinery Beam Saw
Specification
Model | MS270 | |||
Cutting length | 3800mm | |||
Saw shaft speed slot | 9000r/min | |||
Max Thickness | 80mm | |||
Main blade shaft diameter | 300*30mm | |||
Sliding table stroke | 2800mm | |||
Tilt angle of the blade | 45°-90° | |||
Main saw motor | 15kw | |||
Groove saw motor | 2.2kw | |||
Automatic feeding motor | 1.5kw(Adjustable speed) | |||
Slot Blade size | 120×20mm | |||
Weight | 5000kg | |||
Dimensions | 6500*6000*1750mm | |||
Total power | 20.9kw | |||
Advantages
1. High precision: The machine body saw carrier is adopt German technology, the perfect combination of rack and pinion transmission and reducer control, the sawing accuracy is within ±0.15, and the automatic positioning and sawing can be realized for different workpiece width.
2. PLC control system: It can edit and manage the sawing plan, and connect with a variety of sawing software, barcode management software, and automation system.
3. Independent lifting of main and groove saws: The main saw adopts Igarashi motor 15KW, and the groove saw 2.2KW. The maximum work thickness can reach 90mm. While increasing the cutting speed, it reduces the load of the saw blades, making it more durable and stable.
Machine Details
Touch screen control system Safe and reliable operation, simple interface, with complete operation instructions and trouble shooting guide lines. It can edit and manage sawing scheme, edit and manage sawing task, and simulate sawing execution. |
Sawing two linear guides The slide block (Taiwan CSK) ensures the accuracy of the cutting dimension, which is suitable for re cutting with high speed. |
Pressure beam The pressure beam of the electronic cutting saw is made of high-quality steel, with a thick rubber pad at the bottom. In addition, there are two large cylinders on the left and right to drive the lifting, so that both sides of the pressure beam can be pressed up and down synchronously without damaging the plate surface. |
Precision electronic ruler Closed loop precision compensation of German electronic ruler, compensation tolerance +0.02 mm, high precision Swiss gear bar feeding walking mechanism. |
Characteristic:
The electronic cutting saw is equipped with a feeding manipulator to drag the plate for automatic feeding, automatic positioning and automatic cutting. The high-precision servo system controls the feeding accuracy, and the electronic ruler performs accuracy compensation, which effectively ensures the integrity of the plate sawing end face and improves the work efficiency. Another feature of the electronic cutting saw is that it can be operated by ordinary workers without technical maintenance and debugging accuracy. The two people cooperate to save labor costs for the enterprise.
Application
Wood furnitures, aluminum furniture, acrylic, artificial slate and packaging board, etc.
Packing&Shipping
Company profile
FAQ
1. Delivery time of Automatic panel saw?
Standard size and configuration Automatic panel saw delivery time is 15 days.So we suggestion client pay 100% money, because we can can arrange machine delivery immediately.
2. Can you sent machine to my home?
Yes, we have cooperation long time shipping agent, famous team in China, them can offer FCA,FOB, CIF, DDU, DDP price, usual suggest receiver address is Business district, usual less big car drive in the Civil area.
3.This is the first time to use Automatic panel saw,is it easy to operate?
Yes, it is easy, if you can draw with software, the machine operate is no problem, because we will support:
1).English guide video and instruction book are sent to you free together with the Automatic panel saw.
2).Free training course in our factory. Engineers are available to serve overseas but all the expense needs being paid by your side.
3）.We have our own after-sales service team,24 hours technical support by calling, video and email.
4.Term of payment ?
30% T/T in advance, 70% T/T before delivery.After we receive your deposit, we will arrange production,meanwhile machine pictures and videos will be sent to clients in time,when they make sure everything is ok, transfer the balance and we arrange to delivery machine.
5.Does your product exported to our country?
Sure,Our company has been exported to more than 100 countries and has established branches in the UK, France, Poland, Germany,Korea, Georgia, Pakistan, Canada and other countries.
