CNC Foam 3D Carving Router
Product Overview
Features：
3.Intelligent processing cross-border protection, Preventing body collision due to processing format reach out working size.
4. Multi -function contorlling, fot processing speed.travelling speed,and cutting speed.Improving much more quality and efficiency.
Model | GD-1325 GD-1830 GD-2040 |
Working Area | 1300*2500*200 mm 1800*3000mm 4000*2000mm |
Spindle power | 3.2 kw,/4.5kw /5.5kw/6kw/7.5kw(Optional) |
Feeding height | 500-2000mm |
Max processing speed | 30 m/ min |
Spindle speed | 0-24000rpm |
Resolution precision | ±0.05mm |
Software environment | windows98/2000/xp |
Software | TYPE3/Artcam/Castmate/UG/CAD/CAMetc |
Driver | China stepping motors and leadshin driver |
Code | G Code, HPGL Code |
Power Supply | AC380V/50Hz |
Control System | NC Studio / DSP(optional) |
Z axis stroke size can be 1m. wide processing size ,Suitable for greater & thicker materials.
Water-cooled spindle, high power and high precision.
Steel gantry, sturdy and durable to ensure accuracy and strength.
Rotation axis can be added to engrave cylinder material.
Company profile
Certificate
Packing & Delivery
Q1 For offer the most suitable machine,how should i do?
1).The exact material you want to engrave/cut? (such as wood, acrylic, cloth, fabric, leather, metal.... ? )
2). For the Spindle Power, may I know the cutting or engraving depth you want?
3). The working area you demand? (such as max dimension of material, width*length,1200*1200mm,1300*2500mm,2000*3000mm, etc...
4). Do you want to engrave on planar &flat surface or round &curved surface?
If yes,the machine shall be added optional items, such as rotary attachment. if you can provide some pictures of your products,that would be great! after your tell us these,we will send you more information about the machine and price.
Q2.If we donot know how to use the machine,can you teach us?
Yes,we will ,if you come to China,we will offer you free training until you can use machine freely.And if you are busy ,we will have the special engineer to your country,but you need to bear some fee, like tickets and hotel and meal.
Q3.How about your after-sales service?
we offer you 24 hours service phone,skype or MSN.
Q4.How about your guarantee period?
One year and during the time,if you have any questions ,we will solve it for free.
Our Service
1.Engineers available to service machinery overseas.
2.1 year guarantee for whole machine.
3.Technical support by phone,e-mail,whatsapp and skype.If you have any problems,we will within 12 hours to solve it.
4.You will be get free training advice towards our machine in our factory.
5.If you need and component of the machine,we will provide the best price for you.
6.Friendly English version manual and operation video CD disk.
If you have any questions about our products, please contact me with no hesitate..
